　【2-CH Motion Detect Digital Video Recorder】　　　　　　

Mail to:sales@borderless-j.com

■　Feature ■

-Get into working state as soon as power on;

- Automatically take photos/record when detect motive objects;

-. If the object is immobile or the object stops moving, this does not record or stop recording;

- Can connect two cameras, and can detect, take photos or record at the same time;

-. Maximum support double 2Gb SD cards, each store about 28800 photos or 2450 video clips;

-. Memory tenet is "First in, First out" automatically overwrite former images;

-. Supporting all kinds of CCTV cameras(CCD, CMOS);

-. This can supply power(DV12V) to two cameras directly;

-. With "motion detecting signal trigger output" port, can combined with all kinds of alarm system, form new shooting and recording alarm system;

-. The stored photos/video clips will not lose after power off;

-. Optional NTSC/PAL video signal;

-. The parameters(Date, time, Detecting area, sensitivity and interval time etc.) can be reset by user, not lose after power off;

-. The video file named by date saved by AVI format, and photos by JPEG format;

-. User can search, browse and delete image files by date;

-. Can operate this by IR remote;

-. Has the simple menu, no need to install software;

-. Can replay images on TV, Monitor, or Computer(by SD reader).

　Market Unit Price　USD 980.00

　　Whole Sale Unit Price　　　USD　400.00

　　*FOB Tokyo
　　*Terms of payment: TT in advance
　　*Minimum Order Lot:50 sets

■　Technology Parameter 　■

Work Voltage	DC12V
Work Current	<550mA
Video Input	75Ω Typ. 1vp-p
Output Voltage	DC12V
Maximum Capability	2Gb x 2
Photo Format and Pixel	JPEG：640×480
Video Format and Pixel	AVI：320×240
FPS/Second	10fps
Video Record Time	20秒
Compress Format	Motion JPEG
Record Signal	2 channel Video + Audio
Motion Detecting Function	Fnction:2-CH Video has Motion Detect function
Connected Cameras	2 Camera (CMOS&CCD)
Video Input	75Ω Typ:1vp-p
Video Output	75Ω Typ:1vp-p
Mainframe In specification	124mm x 110mm x 26mm
Mainframe Weight	380ｇ
Packing Accessory	One Mainframe; one DC 12V power adapter; two special AVP combined wires; one special AV output wire; two detect signal output control wire; one IR remote, one user manual; two (128M~2G)SD cards(pay extra fee)
